Description
This EZ3045G General Pump features:
- Solid ceramic plungers
- Standard SAE J609 gasoline mounting flange for up to 13 hp engines
- Forged brass manifold with an exclusive lifetime warranty and 4:1 hydrostatic rating
- Die-cast, anodized aluminum, oil-bath crankcase
- Premium roller bearing
- Unitized stainless steel inlet and discharge valves
- Available in L left-handed version
The EZ3045G is rated at:
| Maximum Volume | 4.6 gpm |
| Max. Discharge Pressure | 3000 psi |
| Maximum Pump Speed | 3400 rpm |
| Maximum Inlet Pressure | 125 psi |
| Maximum Inlet Vacuum | 3 ft. water (2.6 in Hg) |
| Bore | .591 in / 15 mm |
| Stroke | .433 in / 11 mm |
| Crankcase Oil Capacity | 14.0 oz |
| Maximum Fluid Temperature | 165°F |
| Inlet Port Thread | 1/2-14 BSPP-F |
| Discharge Port Thread | 3/8-19 BSPP-F |
| Hollow Shaft I.D. | 1.0 in / 25.4 mm |
| Weight | 19.1 lbs |
| Dimensions | 8.8 x 9.7 x 6.5 in |
Repair Parts Available:
Repair Kit 23 – Piston Rod Oil Seal (1602)
Repair Kit 88 – Packing w Restop Ring (1615)
Repair Kit 90 – Head Rings (3874)
Repair Kit 123 – Valve (1616)
Repair Kit 124 – Valve Cap (3868)
Repair Kit 125 – Packing Retainer (3875)
Repair Kit 130 – Packing Assembly (3876)
