Description
The EZ2542E pump by General Pump features
- Triplex Plunger Pump
- Direct Drive with Electric Flange
- Maximum Volume: 4.2 GPM
- Maximum Discharge Pressure: 2500 PSI
- Maximum Inlet Pressure: 125 PSI
- Maximum Pump Speed: 1750 RPM
- Minimum Horsepower Requirements: 7.2 bhp
- Bore: .708″ (18mm)
- Stroke: .612″ (13mm)
- Crankcase Capacity: 14 oz. Nondetergent SAE 30W oil
- Maximum Fluid Temperature: 165 Degrees F.
- Inlet Port Thread: 1/2″ FPT
- Discharge Port Thread: 3/8″ FPT
- Shaft Diameter: 1-1/8″ ID flange
- Dimensions: 8.8″ x 8.8″ x 6.3″
- Weight: 20 lb.
Replacement Parts Available
Valves – Kit 123
Piston Oil Seal – Kit 23
Packing’s – Kit 127
Packing’s with Brass – Kit 131
Pistons – 44040109
Valve Caps – Kit 124
Piston Bolts – 99317500
Crank Oil Seal – 90169000
