Description
DETAILS
The Edelbrock 3835 adapter kit is required to install our Performer 5.0 PN 3821 or Performer RPM PN 7126 in 1994 and 1995 Mustangs. The 1994-1995 throttle body has a different bolt flange and idle air motor than 1987-1993 models. It is also swung out 50 Deg and dropped 1 degree from its previous location. The 3835 locates the throttle body in the stock location and accepts the stock vacuum fitting. Testing on our 1994 Mustang showed a .4 second improvement in 10-70 MPH with our 3821 and 70mm throttle body vs. stock.
SPECS
| Availability | Available |
|---|---|
| Application | Application Specific |
| UPC | 00085347038350 |
| Recommended Use | For Edelbrock Manifolds #3821, #7123, And #7126 |
| Mounting Hole Quantity | 8 |
| Gasket Or Seal Included | Yes |
| Quantity | Sold Individually |
| Bore Diameter | 70 mm |
| Type | Elbow |
| Main Port Inside Diameter | 70.0 mm |
| Mount Hole Inside Diameter | 0.3125 in |
| Main Port Outside Diameter | 0.375 in |
| Availability Note | Available to Order |
| Warranty | 12 Months |
| CARB Executive Order Number | D-215-75 |
| Emissions Code | EO Number: D-215-75 |
| Hazardous Materials Warning |  WARNING: This product can expose you to Lead, which is known to the State of California to cause cancer or birth defects or other reproductive harm. For more information, visit www.P65warnings.ca.gov. |
| Finish | Gray Powder coated |
| Material | Aluminum |
| Port Quantity | 4 |
| Thickness | 0.63 in |
