Description
The Annovi Reverberi RK15.28HN, N version 24mm solid shaft triplex pump is ready for direct or pulley driving. This pump is manufactured with a nickel-plated brass pump head suitable for a wide range of conditions. The RK15.28HN can produce up to 4000 Max PSI, 3.96 Max GPM, and is designed to operate at 1450 RPM. Constructed with frictionless bronze connecting rods and ceramic pistons, the RK15.28HN weighs in at 20 lbs and boasts a sleek compact design.
| Weight | 20 lbs |
|---|---|
| Pump Orientation |
Horizontal |
| Pump Head Material |
nickel plated brass |
| Connecting Rods |
bronze |
| Max GPM |
3.96 |
| Max L/Min |
15 |
| Max PSI |
4000 |
| Max Bar |
275 |
| Power EBHP |
11 |
| Bore Dia mm |
18 |
| Stroke mm |
14.6 |
| CSID Stamp |
1 |
| Inlet (in) |
1/2″ F |
| Outlet (in) |
3/8″ F |
| Max Temp |
140° F |
| Oil Capacity (oz.) |
15 oz |
| RPM |
1450 |
| Shaft Size |
24mm |
| Shaft Version |
Neutral Shaft |
| Shaft Type |
Solid |
| Market |
Commercial |
| Pump Type |
Tri-Plex Plunger |
